A

Arrma

Vorteks 223S

1/10 · Stadium Truck

Prices by Retailer

Best

AMain Hobbies

Updated 20h ago

Horizon Hobby

Updated 20h ago

$339.99
Shop →

About the Vorteks 223S

The Vorteks 223S is Arrma's 1/10 scale 4WD stadium truck. A stadium truck sits between a buggy and a monster truck: it has wider tires and more clearance than a buggy, but a lower body and center of gravity than a monster truck. The Vorteks uses the same 223S electronics as the Granite, Big Rock, Senton and Typhon: a Spektrum SLT 80A waterproof ESC with built-in receiver, a 3100Kv brushless motor with a 35mm fan, an S662 metal-geared servo and an SLT3 radio. It runs on either a 2S or a 3S LiPo.

The chassis numbers line up with the Granite: an 18.5 inch length, an 11.18 inch wheelbase and a weight of 7.56 lb. The difference is the body and the stance. The Vorteks wears a low stadium-truck shell with a rear wing, composite roof rails and a wheelie bar, and runs dBoots tires on multi-spoke wheels. Horizon rates it at 35+ mph on 2S and 50+ mph on 3S.

Inside, it has a ventilated composite chassis, a center differential module, an all-metal gear differential, adjustable oil-filled shocks and a stone guard on the center driveshaft. Spektrum DSC (four-mode steering assist) and SLT3 throttle limiting at 50% or 75% help newer drivers. Like the rest of the 223S family, it uses an IC5 battery connector.

Key Specs

Scale
1/10
Drive
4WD
Motor
Spektrum 3100Kv brushless
Battery
2S or 3S LiPo (not included)
Top Speed
35+ mph on 2S, 50+ mph on 3S
Weight
7.56 lb (3.43 kg)

Who It's For

The Vorteks suits a driver who wants one truck for mixed terrain: some jumps, some pavement, some grass, without going all the way to a monster truck. It handles more predictably than a Granite at speed because it sits lower, and it is more forgiving off-pavement than the Typhon buggy. It works as a first brushless vehicle if you start on 2S with throttle limiting on. If you mostly want big air and rough ground, the Granite or Big Rock is the better fit.

Upgrade Notes

Like every 223S model, the Vorteks ships without a battery or charger. Budget for a 2S or 3S hardcase LiPo with an IC5 connector and a LiPo charger. A 3S pack is the change that makes the biggest difference, and it is a direct swap.

After that, most owners spend on spares and tires rather than performance parts. Front arms and bumpers take most of the crash damage on a basher this size. Tire choice also changes the truck's character: a softer or more open tread for loose dirt, or a harder street tread if you run mostly on pavement.

Common first mods:3S LiPo battery (IC5), LiPo charger, spare front suspension arms, tires, pinion gear

Compatible Parts

Track prices → Premium
Spektrum RC S155 G2 AC Smart Charger (2-4S/5A/55W)$54.99
Spektrum RC 2S Smart LiPo 50C Hard Case Battery Pack (7.4V/5000mAh) w/IC5 Connector$49.99
Spektrum RC 3S Smart G2 LiPo 50C Battery Pack (11.1V/5000mAh) w/IC5 Connector$79.99
Arrma 4x4 Steering Block (2)$4.99
Spektrum RC S100 DC/USB 4S LiPo Smart Charger$34.99

Get alerts when any part drops in price

Upgrade to Premium →

Want an alert when this price drops?

Sign up free →

Price History (last 30 days)

Premium shows 90 days of history.
